Ideal Applications
Commercial & Industrial
Reliable power for shopping malls, factories, and office complexes.
Renewable Energy
Solar and wind farm step-up applications with special duty cycles.
Data Centers
High-reliability power distribution for critical infrastructure.
Technical Specifications
Engineered to meet global standards including ANSI/IEEE C57.12.34 and IEC 60076. Customizable for specific project requirements.
| kVA Rating | 45 - 5000 kVA |
| High Voltage | Up to 35 kV (200 kV BIL) |
| Low Voltage | 208Y/120, 480Y/277, 415Y/240 V |
| Frequency | 50 Hz / 60 Hz |
| Cooling Class | ONAN / ONAF (Mineral Oil or FR3) |
| Standard | ANSI/IEEE C57.12.34 / IEC 60076 |
| Winding Material | Copper or Aluminum |
Advanced Features
- Dead-front design for operator safety
- Load break switches (2-position or 4-position)
- Current limiting fuses / Bay-O-Net fuses
- Liquid level, temperature, and pressure gauges
- Pressure relief device
- Dual voltage switching (optional)
- Stainless steel cabinet (optional for coastal areas)
Special Designs
We offer K-Factor rated transformers for non-linear loads and Solar/Wind duty designs.
